5059 Aluminum Bar
5059 Aluminum Bar is a high-strength, corrosion-resistant marine-grade alloy primarily used in shipbuilding, offshore structures, and defense applications. It offers excellent weldability, toughness, and fatigue resistance, making it ideal for demanding environments. Manufactured to ASTM B211 and EN 573 standards, 5059 aluminum bar features a tensile strength of up to 400 MPa and outstanding resistance to seawater corrosion. SASA ALUMINUM supplies 5059 aluminum bars in customized sizes and tempers with fast delivery and strict quality control to meet various industrial and marine engineering requirements.
| Specifications of 5059 Aluminum bar: |
| Grade | 5059 |
| Diameter | 3mm to 300mm or as the customer’s request |
| Temper | H112 |
| Length | Common 1500/3000/5000/6000MM |
| Surface | Anodized, Polished, hair line, brush |
| Mill Test Certificate | EN 10204 3.1 or EN 10204 3.2 |
| Chemical Composition of 5059 Aluminum bar: |
| Element | 5059 % |
| Al | Rest |
| Mg | 4.8-5.5 |
| Mn | 0.5-1.0 |
| Cr | 0.05-0.25 |
| Zn | 0.25-0.6 |
| Cu | 0.1 |
| Ti | 0.15-0.35 |
| Si | 0.25 |
| Fe | 0.4 |
| Sn | 0.2 |
| Mechanical Properties of 5059 aluminum bar |
| Alloy | Temper | Thickness ｍｍ | Tensile Strength Rｍ MPa | Specified non-proportional tensile strength Rp0.2 Mpa | Elongation ％ | |
| A50 ｍｍ | A | |||||
| 5059 | H112 | ≤12.50 | 330 | 200 | - | 10 |
| >12.5-50.00 | 330 | 200 | 10 | - | ||
| 5086 | O | ≤12.50 | 240-315 | 95 | - | 15 |
| >12.50-200.00 | 240-315 | 95 | 18 | - | ||
| H112 | ≤12.50 | 240 | 95 | - | 12 | |
| >12.50-250.0 | 240 | 95 | 12 | - | ||
| Characteristics of Aluminum 5059 Round Bar |
-
Lightweight & High Strength:
Reduce overall hull weight while improving ship load-carrying efficiency and fuel performance. -
Excellent Corrosion Resistance:
Outstanding resistance to seawater, salt spray, and marine atmosphere, ensuring long-term durability. -
Superior Weldability:
Both alloys can be easily welded using MIG or TIG methods, producing joints with strength comparable to the base metal. -
Good Formability & Machinability:
Easy to machine, cut, and shape to meet diverse shipbuilding and structural design needs. -
Wide Marine Applications:
Ideal for ship hulls, decks, superstructures, pressure vessels, and offshore platforms operating under heavy loads.
| Applications of Aluminum Alloy 5059 Bar: |
5059 Aluminum Bar is widely used in marine and offshore engineering due to its exceptional corrosion resistance and high strength. It is an ideal material for ship hulls, decks, superstructures, and bulkheads, offering long service life in seawater environments. In addition, it is used in offshore oil platforms, pressure vessels, armor plating, and transport vehicle frames, where strength-to-weight ratio and durability are critical. The alloy’s excellent weldability also makes it suitable for bridge structures, cranes, and storage tanks exposed to harsh marine or industrial conditions.
| Why Choose us |
1. You can get the perfect material according to your requirement at the least possible price.
2. We also offer Reworks, FOB, CFR, CIF, and door to door delivery prices. We suggest you to do deal for shipping which will be quite economical.
3. The materials we provide are completely verifiable, right from raw material test certificate to the final dimensional statement.(Reports will show on requirement)
4. We guarantee to give a response within 24hours(usually in the same hour)
5. Provide SGS TUV report.
6. We are fully dedicated to our customers. If it will not possible to meet your requirements after examining all options, we will not mislead you by making false promises which will create good customer relations.
7.Provide one-stop service.
| Aluminum bar Manufacturers Packing |
1. Packing is quite important especially in a case of international shipments in which consignment pass through various channels to reach the ultimate destination, so we put special concern regarding packaging.
2. Sasa aluminum’s pack our goods in numerous ways based on the products. We pack our products in multiple ways, such as
