Aircraft Grade Aluminum 7175 Sheet – Heat Treatable Alloy
Aluminum 7175 sheet is a wrought aluminum-zinc-magnesium-copper alloy designed for critical structural applications. With mechanical properties similar to 7075 but improved stress corrosion cracking resistance, 7175 is ideal for use in aerospace and defense industries. It is typically supplied in T6 or T651 tempers to deliver optimal strength and stability.
| Specifications of 7175 Aluminum Plate: |
| Alloy | 7175 |
| Standard | ASTM B209 / ASME SB209 |
| Thickness | 3.0mm-200mm |
| Width | 500-2600mm |
| Length | to clients’ requirement |
| Certificate of Classification | Classification Society (CCS), American Classification Society (ABS), French Classification Society (BV), British Classification Society (LR) Classification society certification. |
| Finish | PVDF, POLYESTER(PE) |
| Surface | Bright, polished, hair line, brush, sand blast, checkered, embossed, etching, etc. |
| Chemical Composition of 7175 alloy Plate: |
| Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti |
| 0.12 | 0.15 | 2.0-2.6 | 0.10 | 1.9-2.6 | 0.04 | 5.7-6.7 | 0.08-0.21 |
| Mechanical property of 7475 aluminum sheet: |
| Density | Melting Point | Tensile Strength | Yield Strength | Elongation |
| 2.80 g/cm³ | 477 °C | 435 MPa | 505 MPa | 13 % |
| 7175 aluminum plate application: |
-
Aircraft wing spars and fuselage frames
-
Landing gear components
-
Military aerospace structures
-
Structural parts in robotics and machinery
-
High-performance automotive components
| FAQ |
Q1: What is the difference between 7175 and 7075 aluminum sheet?
A: While both are high-strength alloys, 7175 has better stress corrosion resistance and is mainly used for aerospace structural parts, offering improved performance under cyclic stress.
Q2: Is 7175 aluminum weldable?
A: No, 7175 aluminum is generally not recommended for welding due to its susceptibility to cracking. Mechanical fastening is preferred.
Q3: What tempers are available for 7175 aluminum sheet?
A: The most common tempers are T6 and T651, which provide high strength and dimensional stability.
Q4: Can you provide test certificates and material traceability?
A: Yes. sasaaluminum supplies 7175 aluminum sheets with full Mill Test Certificates (MTC) and EN 10204 3.1 documentation upon request.
Q5: What packaging options are available?
A: Standard export seaworthy wooden pallets, vacuum-packed if required, ensuring safe delivery worldwide.
