6101-T6 Aluminium Plate
If you need an Aluminum Alloy Plate with high conductivity, 6101 Aluminum Plate is a good solution. Aluminium 6101-T6 Plate (UNS a96101) is an aluminum bar containing a heat treatable wrought alloy best suited for applications involving moderate strength and maximum electrical conductivity.
6101-T6 Aluminium Plate is a high electrical conductivity aluminum alloy which has good mechanical properties and good machinability, formability and weldability. It is commonly used for electrical bus bar conductor applications in enclosed bus electrical installations.
| Standard Dimensions of 6101-T6 Aluminium Plate |
| Aluminium Alloy | ASTM B209 6101-T6 |
| Aluminium 6101-T6 Plate Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium 6101-T6 Plate Thickness | 0.5mm-150mm |
| Aluminium 6101-T6 Plate Width | 500-2000mm |
| Aluminium 6101-T6 Plate Length | to clients’ requirement |
| Aluminium 6101-T6 Plate Coating | Polyester, Fluorocarbon, polyurethane and epoxy coating |
| 6101-T6 Aluminium Plate Coating finish | PVDF, POLYESTER(PE) |
| Aluminium 6101-T6 Plate Surface | Polished, hair line, brush, sand blast, checkered, embossed, etching, etc. Mill finish, Bright finish, paper interleaved, one side film, both sides film. |
| Aluminium 6101-T6 Plate Gloss | Meet the customer requirement |
| Total coating thickness of Aluminium 6101-T6 Plate | PVDF coating: More than 25 micron; Polyester coating: More than 18 micron |
| Aluminium 6101-T6 Plate Coating hardness | (pencil hardness) more than 2H |
| Aluminium 6101-T6 Plate Coating adhesive | No lower than1st grade |
| Aluminium 6101-T6 Plate Impact resistance | No cracking or peeling (50kg/cm, ASTMD-2794: 1993) |
| Aluminium 6101-T6 Plate Flexibility (T-bend) | 2T |
| Aluminium 6101-T6 Plate MEK resistance | More than 10 |
| Available Aluminium 6101-T6 Plate Stock Sizes | 1ft x 1ft, 1ft x 2ft, 1ft x 4ft, 2ft x 2ft, 2ft x 4ft, 4ft x 4ft, 4ft x 8ft, 4ft x 10ft or Cut to Size or Custom Shape. |
| Aluminium 6101-T6 Plate Delivery Time | 30-60 days after receiving the prepayment |
| Aluminium 6101-T6 Plate Packaging Details | Standard export package. One pallet is about 2-3 ton.Two steel belts in width and three in width. One 20GP container can load about 18-20 tons Aluminium 6101-T6 Plate. One 40GP container can load about 24 tons Aluminium 6101-T6 Plate |
| ASTM B209 Alloy 6101-T6 Plate Outer packing | Export standard, wooden pallet |
| Bottom side Aluminium 6101-T6 Plate is coated with protective polyester material, thickness more than 6 micron | |
| We Export Aluminium 6101-T6 Plate to | Singapore, Indonesia, Ukraine, Korea, Thailand, Vietnam, Saudi Arabia, Brazil, Spain, Canada, USA, Egypt, Iran, China, Kuwait, Dubai, Oman, Kuwait, Peru, Mexico, Iraq, Russia, Malaysia, etc. |
| Types of 6101-T6 Aluminium Plate Manufacturer in China: |
| 6101-T6 Aluminium Plates Product Range | ||||
|---|---|---|---|---|
| Alloy No. | Thickness (mm) |
Width (mm) |
Length (mm) |
Temper |
| 6101-T6 Aluminium Plate | 0.2-5.0 | 20-2200 | 20-8000 | O, H12, H22, H14, H16, H18, H24, H26 |
| Standard Specification of 6101-T6 Aluminium Plate: |
| European Standard | BS (OLD) | USA (AA) | GERMANY (DIN) | ISO | IS | Canadian |
|---|---|---|---|---|---|---|
| EN AW-6101A | E91E | 6101 | E AlMgSi 0.5 | E AlMgSi(A) | 63401 | D50S |
| 6101-T6 Aluminium Plate Equivalent Grades: |
| China |
U.S.A. |
BRITAIN |
CANADA | GERMANY |
RUSSIA |
I.S.O. |
FRENCH | |
|---|---|---|---|---|---|---|---|---|
| New IS | Old IS | (A.A.) |
(B.S.) |
(DIN) | – | – | – | |
| 63401 | 91E | 6101 | 91E | D50S | E.Al.Mg.Si 0.5 | – | – | – |
| 6101-T6 Aluminium Plate Sizes: |
| Sizes (mm) | Theoretical Mass KG/Plate |
|---|---|
| 2000 X 1000 X 0.5 | 2500 X 1250 X 0.5 |
| 2000 X 1000 X 0.7 | 2500 X 1250 X 0.7 |
| 2000 X 1000 X 0.9 | 2500 X 1250 X 0.9 |
| 2000 X 1000 X 1.2 | 2500 X 1250 X 1.2 |
| 3000 X 1500 X 1.2 | 2000 X 1000 X 1.6 |
| 2500 X 1250 X 1.6 | 3000 X 1500 X 1.6 |
| 2000 X 1000 X 2.0 | 2500 X 1250 X 2.0 |
| 3000 X 1500 X 2.0 | 2500 X 1250 X 2.5 |
| 2.79 | 4.36 |
| 3.91 | 6.10 |
| 5.02 | 7.85 |
| 6.74 | 10.46 |
| 15.01 | 8.93 |
| 13.95 | 20.09 |
| 11.16 | 17.44 |
| 25.11 | 21.80 |
| 6101-T6 Aluminium Plate Weight Chart: |
Width: 1.000 mm | Length: 2.000 mm
| Product | Thickness | Weight |
|---|---|---|
| 6101-T6 Aluminium Plate | 0,30 mm | 0,810 Kg/m2 |
| 6101-T6 Aluminium Plate | 0,40 mm | 1,080 Kg/m2 |
| 6101-T6 Aluminium Plate | 0,50 mm | 1,350 Kg/m2 |
| 6101-T6 Aluminium Plate | 0,60 mm | 1,620 Kg/m2 |
| 6101-T6 Aluminium Plate | 0,70 mm | 1,890 Kg/m2 |
| 6101-T6 Aluminium Plate | 0,80 mm | 2,160 Kg/m2 |
| 6101-T6 Aluminium Plate | 0,90 mm | 2,430 Kg/m2 |
| 6101-T6 Aluminium Plate | 1,00 mm | 2,700 Kg/m2 |
| 6101-T6 Aluminium Plate | 1,20 mm | 3,240 Kg/m2 |
| 6101-T6 Aluminium Plate | 1,40 mm | 3,780 Kg/m2 |
| 6101-T6 Aluminium Plate | 1,50 mm | 4,050 Kg/m2 |
| 6101-T6 Aluminium Plate | 1,60 mm | 4,320 Kg/m2 |
| 6101-T6 Aluminium Plate | 1,80 mm | 4,860 Kg/m2 |
| 6101-T6 Aluminium Plate | 2,00 mm | 5,400 Kg/m2 |
| 6101-T6 Aluminium Plate | 2,20 mm | 5,940 Kg/m2 |
| 6101-T6 Aluminium Plate | 2,50 mm | 6,750 Kg/m2 |
| 6101-T6 Aluminium Plate | 3,00 mm | 8,100 Kg/m2 |
| 6101-T6 Aluminium Plate | 4,00 mm | 10,800 Kg/m2 |
| 6101-T6 Aluminium Plate | 5,00 mm | 13,500 Kg/m2 |
| 6101-T6 Aluminium Plate | 6,00 mm | 16,200 Kg/m2 |
| 6101-T6 Aluminium Plate | 10,00 mm | 27,000 Kg/m2 |
| 6101-T6 Aluminium Plate | 12,00 mm | 32,400 Kg/m2 |
| 6101-T6 Aluminium Plate | 15,00 mm | 40,500 Kg/m2 |
| 6101-T6 Aluminium Plate | 20,00 mm | 54,000 Kg/m2 |
| 6101-T6 Aluminium Plate Chemical Composition: |
| Weight % | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | B | Each | Total |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Minimum | 0.30 | 0.35 | |||||||||
| Maximum | 0.70 | 0.50 | 0.10 | 0.03 | 0.80 | 0.03 | 0.10 | – | 0.06 | 0.03 | 0.10 |
| Aluminium 6101-T6 Plate Mechanical Properties: |
| Temper | Tensile | Hardness | ||||
|---|---|---|---|---|---|---|
| Ultimate | Yield | Elongation | Brinell | |||
| KSI | MPA | KSI | MPA | % | ||
| T6 | 29 | 200 | 25 | 172 | 15 | 71 |
| T61 | 15 | 103 | 8 | 55 | ||
Aluminum Alloy Heat Treatment Temper Designations
Basic Aluminum Heat Treatment Designations
- F As Fabricated
- O Annealed
- H Strain Hardened
- W Solution Heat Treated
- T Solution Heat Treated
Heat Treating T Temper Codes for Aluminium 6101-T6 Plates
- T1 – Cooled from an elevated temperature shaping process and naturally aged to a substantially stable condition.
- T2 – Cooled from an elevated temperature shaping process, cold worked, and naturally aged to a substantially stable condition.
- T3 – Solution heat treated, cold worked, and naturally aged to a substantially stable condition.
- T4 – Solution heat treated, and naturally aged to a substantially stable condition.
- T5 – Cooled from an elevated temperature shaping process then artificially aged.
- T6 – Solution heat treated then artificially aged.
- T7 – Solution heat treated then overaged/stabilized.
- T8 – Solution heat treated, cold worked, then artificially aged.
- T9 – Solution heat treated, artificially aged, then cold worked.
- T10 – Cooled from an elevated temperature shaping process, cold worked, then artificially aged.
Additional digits may be used after the first T temper digit to indicate subsequent stress relieving by processes such as stretching, compressing, or a combination.
H Temper Strain Hardening Codes for Aluminium 6101-T6 Plates
- H1 – Strain hardened only
- H2 – Strain hardened and partially annealed
- H3 – Strain hardened and stabilized
- H4 – Strain hardened and lacquered or painted. This assumes that thermal affects from the coating process affect the strain hardening; seldom encountered.
Application of 6101-T6 Aluminium Plate
6101-T6 Aluminium Plate is the most widely used form of Industrial Aluminium. 6101-T6 Aluminium Plates find applications in various industries such as manufacturing cans and packages, transportation, home appliances, building and construction.
