Aluminium Alloy 3003 Flanges

Short Description:


  • Dimensions : ANSI/ASME B16.5
  • Size : 1/2” NB TO 24” NB
  • Class / Pressure: 150#, 300#, 600#, 900#
  • Flange Face Types: FF RF RTJ
  • Product Detail

    FAQ

    Product Tags

    Aluminium Flanges are widely used in many industrial applications. Application in which these flanges are used such as Paper Industries, Oil and gas Industries, Pharmaceutical plant, Fertilizer plant, Food & dairy plants, Petrochemicals, Chemical industries, Desalination plant and many more. These flanges also used in power plants, nuclear plants, water system pipe projects, electric power, etc. After the manufacturing of these flanges, they are tested for different quality inspections to ensure the durability of these flanges. This is done by the following tests such as PMI test, IGC test, hardness test, tensile test, chemical test, mechanical test, micro & macro test, etc.

    Specificaton for Aluminium flanges:

    Dimensions : ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc

    Standard :  ASTM B247

    Size : 1/2” NB TO 24” NB

    Class / Pressure : 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64, PN100, PN160 etc.

    Flange Face Types / Connection Type: Flat Face Flange (FF), Raised Face Flange (RF), Ring Joint Flange (RTJ);

    Custom Design:  As per your drawing | AS, BS, ANSI, DIN, JIS | Equal and Reducing Configurations

    Material Test Certificates (MTC) : As per EN 10204 3.2 and EN 10204 3.1, Test Certificates NACE MR0175, NACE MR0103;

    Test: Certificates: 100% Radiography Test Report, EN 10204/3.1B, Raw Materials,  Third Party Inspection Report, etc

    Tests : Hydrostatic testing machine, Direct-reading Spectrograph, UI trasonic flaw detector, X-ray detector;

    Equipment / Machines : Press machine, Pushing Machine, Bending machine, Sand-blasting machine, etc.

    Coating : Anti-rust Paint, Oil Black Paint, Yellow Transparent, Zinc Plated, Cold and Hot Dip Galvanized

    Applications/Usage : Offshore, Oil Field, Shipbuilding, Water System, Natural Gas, Pipe Projects, Electric Power, etc.



    Aluminium Alloy 3003 Flanges Equivalent Grades:
    STANDARD UNS EN DIN ISO USA OLD
    3003 A93003 AW-AlCu4Mg1 AlCuMg2
    AlCu4Mg 3003 AU4G1



    Aluminium Alloy 3003 Flanges Chemical Composition
    Grade Si Al Fe Cu Mn Zn
    3003 0.6max rem 0.7max 0.05-0.20 1.0-1.5 0.1max



    ALUMINIUM ALLOY 3003 FLANGE STANDARDS:
    ANSI/ASME B16.47 Flanges ANSI/ASME B16.36 Flanges ANSI/ASME B16.5 Flanges Pr. EN1902-1 Flanges
    DIN Flanges JIS Flanges BS 4504 Flanges BS 10 Flanges
    MSS SP-44 Flanges JIS B2220 Flanges KS B1503 Flanges UNI Flanges
    SABS/SANS 1123 Flanges AS 2129, AS 4087 Flanges ISO 9624, ISO 7005-1 Flanges AWWA Flanges Standard
    GOST Standard Flanges API Flanges AS/ANZ 4331.1 Flanges Series A Flange
    Series B Flange SAE J518 Flanges GB Flange Norwegian Standard Flanges



    Why Choose Us :

    1. You can get the perfect material according to your requirement at the least possible price.
    2. We also offer Reworks, FOB, CFR, CIF, and door to door delivery prices. We suggest you to do deal for shipping which will be quite economical.
    3. The materials we provide are completely verifiable, right from raw material test certificate to the final dimensional statement.(Reports will show on requirement)
    4. e guarantee to give a response within 24hours(usually in the same hour)
    5. You can get stock alternatives, mill deliveries with minimizing manufacturing time.
    6. We are fully dedicated to our customers. If it will not possible to meet your requirements after examining all options, we will not mislead you by making false promises which will create good customer relations.



    SASA ALUMINUM’S Quality Assurance (including both Destructive and Non-Destructive) :

    1. Visual Dimension Test
    2. Mechanical examining like tensile, Elongation and reduction of area.
    3. Ultrasonic test
    4. Chemical examination analysis
    5. Hardness test
    6. Pitting protection test
    7. Penetrant Test
    8. Intergranular Corrosion Testing
    9. Impact analysis
    10. Metallography Experimental Test



    Sasa Aluminum’S Packaging:

    1. Packing is quite important especially in a case of international shipments in which consignment pass through various channels to reach the ultimate destination, so we put special concern regarding packaging.
    2. Sasa Aluminum’s pack our goods in numerous ways based on the products. We pack our products in multiple ways, such as,

    Aluminium Alloy 7075 Blind Flanges Package     Aluminium Alloy 7075 Flanges package



    ASTM B247 ALUMINIUM ALLOY 3003 FLANGES INDUSTRIES AND APPLICATIONS:

    1.Pumps, Valves, and vessels in manufacturing and food processing.
    2.Pipe connections in industrial waterworks.
    3.Heat exchangers and heating systems of all sizes.
    4.Mining support.
    5.Nuclear power systems.
    6.Plumbing and mechanical systems.
    7. Assemblies in the oil, gas, and petrochemical industries.
    8. Fire protection systems.
